Name: RedevelopmentPlan

Display Field: FID_OverlayDistrict

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Polygon layers of various Overlay Districts in and near Johnson City with more restrictive or varied design guidelines than the zoning layer. Data is published as service with other design overlays and zonings to allow residents to look up zoning for any property of interest.</SPAN></P><P><SPAN>CO: </SPAN><SPAN>Polygon layer used to show Corridor Overlay zoning district in Johnson City. Developed from four major roadway centerlines. 300 ft buffer from ROW of N Roan St, Bristol Hwy, Boones Creek Rd, and Bobby Hicks Hwy. </SPAN></P><P><SPAN>DO: Polygon layer used to show Design Overlay zoning district in Johnson City. Developed from two major roads centerlines. 300 ft buffer from ROW of portions of W State of Franklin Rd and N State of Franklin Rd. </SPAN></P><P><SPAN>GO: Polygon layer used to show Gateway Overlay zoning district in Johnson City. Developed from four major roadway centerlines. 300 ft buffer from ROW portion of W MARKET ST. </SPAN></P><P><SPAN>HD: Polygon layer used to show Historic-Conservation Overlay zoning district in Johnson City. Polygons were developed using a 1985 historical survey of properties older than 50 years having historical significance. </SPAN></P><P><SPAN>UCO: Polygon layer used to show the Urban Commercial Overlay zoning district in Johnson City. Developed along the south side of W Walnut St, properties between the street and the ally behind the businesses. </SPAN></P><P><SPAN>UPO: Polygon layer used to show the University Parkway Overlay zoning district in Johnson City. Developed along the areas near University Parkway. </SPAN></P></DIV></DIV></DIV>

Service Item Id: 606a65302022430eabad1f3500b55471

Copyright Text: City of Johnson City Planning and GIS Divisions.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3023162.531242337
YMin: 737184.3685115129
XMax: 3046186.0498277545
YMax: 770522.325129427
Spatial Reference: 102736  (2274)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: AreaName
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Default Label:
UniqueValueInfos:
• Value: Historic District within Redevelopment District
  Label: Historic District within Redevelopment District
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [137, 90, 68, 255]
  Outline:
  Style: esriSLSSolid
  Color: [137, 90, 68, 255]
  Width: 2
• Value: Redevelopment District
  Label: Redevelopment District
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 255, 190, 102]
  Outline:
  Style: esriSLSSolid
  Color: [115, 76, 0, 255]
  Width: 2
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• FID_OverlayDistrict ( type: esriFieldTypeInteger, alias: FID_OverlayDistrict )
• FID_SpecialTaxDistrict ( type: esriFieldTypeInteger, alias: FID_SpecialTaxDistrict )
• SHAPE_Length ( type: esriFieldTypeDouble, alias: SHAPE_Length )
• SHAPE_Area ( type: esriFieldTypeDouble, alias: SHAPE_Area )
• AreaName ( type: esriFieldTypeString, alias: AreaName, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Relationships:

• RedevelopmentPlan_Pts (0) -- Related To: RedevelopmentPlan_Pts (0)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
